Q2 7” Colour Waterproof Monitor

Q2 7” Colour Waterproof Monitor
  • 4 Channel
  • Water Resistant (IP67)
  • Aluminium Housing
  • Up to 4 Camera Inputs
  • User can Choose Spilt Screen (2/3/4/H Split Screen)
  • 181 x 134 x 28 mm
  Specifications
  Screen Size   7 inch (177.8 mm)
  Resolution   800 (w) x WGGA x 480 (h)
  Brightness   400 CD
  View Angle (L/R/U/D)   70°/70°/50°/70° 
  Power Supply   12 - 24 Vdc/450 mA
  Input System   NTSC/PAL
  Video Signal   Composite Video (CVBS)
  Audio Signal   Mono
  Buttons   (Remote Sensor) Dimmer/ Mode/ Down/ Up/ Left/ Right/ Menu/ Power
  Operating Temperature   -30° C ~ 70° C
  Dimensions (w x h x d)   181 x 134 x 28 mm
  Weight   780 g


Part No.: T170014878
