Alfatronix Voltage Converter

Alfatronix Voltage Converter
Alfatronix offers a convenient way to operate mass produced 12 Vdc equipment such as cell phones, in-car entertainment, professional communications, telematics equipment, refrigerators, televisions, etc. from the 24 Vdc mobile electrical systems found on diesel-engined vehicles and vessels such as emergency services, as well as other applications such as fog machines and passenger counting systems.

These units are IP53, so there are no ventilation holes to permit stray objects, dust, or water droplets to enter the case, there are no external fuses to be tampered with. Fuses will only blow if there is a fault so there is no need to make them accessible.

Alfatronix units consume an offload current of less than 15 mA, which is probably less than the self discharge current of the vehicle’s battery. In most cases this can be ignored, speeding the installation by removing the need to fit a remote switch.

This product fits onto a “Click ‘n’ Fit” mounting clip which is fixed in three points allowing it to be mounted on uneven surfaces. It is easy to fit the clip into awkward places and then simply click the unit into position. A fixing kit for din rail installation is also available. A green LED indicates when there is output from the converter. This gives reassurance to the installation engineer and speeds fault finding.

  • 24 - 12 V
  • 18/21 Amp
  • Non-Isolated
  • 216 w
  • 620 g
  • 167 x 87 x 50 mm

Part No.: T286512807
OE No.: PV18S
